Changing Your F/X CAD License Type

Issue

You need to change your F/X CAD license type after installing.

F/X CAD 2022 users:

If you've purchased F/X CAD 2022, use the F/X CAD 2022 steps below to run the software in Trial mode while waiting for your activation email with your custom Serial Number and Product Key. After receiving your email with these items, you can switch back to the Serial Number license type to activate and use your purchased license.

Other reasons for needing to change your F/X CAD license type:

  • You may have mistakenly selected the Trial option on the screen where you select your license type, and you now see a mostly empty white box in the middle of the screen on startup, with the text appearing so far off the screen that you can't read or click anything. Changing your license type will get rid of this white box.
  • You may also have received a FlexNet License Finder error upon opening CAD.
  • For some versions, you may be missing the activation splash screen on startup and need to activate F/X CAD. These steps will allow you to re-enter your product information and open the activation screen.





Solution

Your solution will depend on your version of F/X CAD:





Changing your F/X CAD 2022 license type (Trial or Serial Number)

Use these steps if you need to:

  • Run F/X CAD 2022 in trial mode while waiting for your activation email with your custom Serial Number and Product Key
  • Switch out of trial mode to activate your F/X CAD 2022 license after receiving your activation email





1. Close F/X CAD.





2. Open the Windows Start menu.





3. Scroll down to the F-X CAD 2022 item and click it to expand it.





4. Click Change F-X CAD License Type.







5. You'll be brought to the Change License Type dialog box.



You'll see Current License Type above the button for your current F/X CAD license type. This example shows a purchased license (Serial Number).



  • If you've purchased F/X CAD 2022 and want to run the software in trial mode while waiting for your activation email, click Trial.



  • If you're currently running F/X CAD in trial mode and you've received your activation email from us and are ready to activate F/X CAD 2022, click Serial Number.



After choosing your license type, click Close to save the change and close this dialog box.



You can now open F/X CAD 2022 and either:

Important notes on the license types and F/X CAD 2022 activation:

The Trial license type requires you to sign in to a free Autodesk account before you can use F/X CAD 2022, and you may see screens offering Autodesk discounts that are irrelevant to F/X CAD. You can simply close these screens.



If you select the Serial Number option, the software will not function until you enter your F/X CAD 2022 Serial Number and Product Key.







Changing your license type: F/X CAD 2021 & older



1. Open the Start menu.





2. Type CMD in the text field.





3. Select the Command Prompt entry.



The Windows Command line will open.







4. Copy and paste the following text at the command prompt:

cd %CommonProgramFiles(x86)%\Autodesk Shared\AdskLicensing\Current\helper\



Then press Enter.







5. Copy the following text, and paste it at the Command prompt:

AdskLicensingInstHelper change -pk 001L1 -pv 2020.0.0.F -lm ""



Then press Enter.

If you choose to type this command manually, note that the phrase -lm includes a lowercase L – not the number 1.



You should now be able to use F/X CAD without issue.

C:\CommonProgramFiles(x86)\Autodesk Shared\AdskLicensing\Current\helper\>AdskLicensingInstHelper change -pk 001L1 -pv 2020.0.0.F -lm ""



Getting feature failed: Get http://127.0.0.1:54091/api/vl/feature: dial tcp 127.0.0.1:54091: connected: No connection could be made because the target machine actively refused it.





Did you see this error at this point? If so, follow our instructions to address the error. Then try Step 5 again.





Unable to switch license types, or seeing another error message at this point?



Use the link below.





1. Close all Autodesk applications, including the Autodesk Desktop App.







2. Right-click the taskbar and select Task Manager from the menu that opens.







3. In the Task Manager, select the option for More details.







4. Select the Details tab.



End each of the following processes, if listed:

  • AutodeskDesktopApp.exe
  • AdAppMgrSvs.exe



To end each of these processes, select it and then click End task.

Don't see these processes in this location? Move on to the next step.







5. Open Windows Explorer, then copy and paste the following folder location into the file path: %LOCALAPPDATA%\Autodesk\Web Services\



Press Enter to navigate to the pasted folder location, then delete the file LoginState.xml.

Don't see the file LoginState.xml in this location? Move on to the next step.







6. Navigate to the location C:\Program Files (x86)\Common Files\Autodesk Shared\AdskLicensing.



Right-click the file uninstall.exe, then select Run As Administrator from the menu that opens.

If you see an Unknown Error message at this point, ensure that the following items are closed:

  • Task Manager
  • Windows Services console







7. Navigate to C:\ProgramData\Autodesk\.



Delete the folder AdskLicensingService from this location.







8. Ensure that the account LOCAL SERVICE has Full Control permission over the following folders:

  • C:\Program Files (x86)\Common Files\Autodesk Shared\AdskLicensing
  • C:\ProgramData\Autodesk\AdskLicensingService

Need help changing these files' permissions? See our instructions for changing file or folder permissions.

If these folders are missing, move on to the next step.







9. Restart your computer.







10. Follow our steps to temporarily disable User Account Control (UAC) in Windows. Also disable any antivirus software you have installed on your computer.







11. Download and install the latest Autodesk Licensing Service Update using the link below.









12. Uninstall F/X CAD 2020.







13. Reinstall F/X CAD 2020.







14. Don't forget to re-enable your User Account Control (UAC) setting, as well as any antivirus software you've disabled temporarily in completing these steps.

Still seeing an error message at this point?

Add exceptions to any antivirus or protection software for the two programs listed below.



• C:\Program Files (x86)\Common Files\Autodesk Shared\AdskLicensing\Current\

AdskLicensingService\AdskLicensingService.exe



• C:\Program Files (x86)\Common Files\Autodesk Shared\AdskLicensing\Current\

AdskLicensingAgent\AdskLicensingAgent.exe



If you continue to see an error message, try disabling or removing your protection software temporarily. You can enabe or reinstall it after you've changed your license type.















1. Type About in the Command line, and press Enter.





2. The About dialog box will open.





Click the Manage License button.







3. The License Manager will open. Click Change License Type.









4. The Change License Type dialog box will open. Click Change.









5. FX CAD will now ask you to either Save drawings and quit, or Quit without saving.





Select the option of your choice, depending on whether you need to save your drawing.





F/X CAD will close.







6. Start F/X CAD again. You'll now see the Let's Get Started screen, pictured below. Click Enter a Serial Number. You can then enter the Serial Number and Product Key for your installation of F/X CAD.





You or your office will have received an F/X CAD Serial Number and Product Key in an email from Land F/X.



You should now be able to use F/X CAD without issue.
